| Medium | R134a / R1234yf / R410a / R290 |
| Flow direction | Bi-directional |
| Full open orifice diameter | 11 mm / 16 mm |
| Ambient temperature | -40 ℃ to 125 ℃ |
| External Leakage | ≤ 1.5 g/y |
| Internal Leakage | ≤ 100 mL/min (@1.0 MPa ∆P air) |
| Max. operation pressure difference | ≥ 2.5MPa |
| Input voltage | 9 V to 16 V |
| Communication | LIN / PWM |
